ASROCK μητρική A520M-HVS, 2x DDR4, AM4, USB 3.2, mATX

ASROCK μητρική A520M-HVS, 2x DDR4, AM4, USB 3.2, mATX

Η A520M-HVS της Asrock είναι μια αξιόπιστη μητρική κάρτα, ιδανική για χρήση τόσο σε home PC όσο και σε bussiness PC. Κατασκευάζεται από αξιόπιστα components και εξοπλίζεται με όλες τις σύγχρονες τεχνολογίες που προσφέρουν αυξημένες ταχύτητες και σταθερή απόδοση. Υποστηρίζει επεξεργαστές οι οποίοι είναι συμβατοί με το socket AM4 και βασίζεται στο chipset A520 της AMD.
Διαθέτει δυο εξόδους γραφικών: D-Sub και HDMI.

-Supports AMD AM4 Socket Ryzen™ 3000, 4000 G-Series and 5000 and 5000 G-Series Desktop Processors*
-6 Phase Power Design
-Supports DDR4 4733+ (OC)
-1 x PCIe 3.0 x16, 1 x PCIe 3.0 x1
-Graphics Output Options: D-Sub, HDMI
-7.1 CH HD Audio (Realtek ALC887 Audio Codec)
-4x SATA3, 1 x Ultra M.2(Gen3 x4 & SATA3)
-6x USB 3.2 Gen1(4 x Rear, 2 x Front)
-6x USB 2.0(2 x Rear, 4 x Front)
-Realtek Gigabit LAN

Τεχνικά Χαρακτηριστικά
CPU: AMD AM4 Socket Ryzen™ 3000, 4000 G-Series, 5000 & 5000 G-Series Desktop Processors
Chipset: AMD A520
Memory: 2x DDR4 DIMM Slots, 15μ Gold Contact in DIMM Slots
Max. capacity of system memory: 64GB
BIOS: 128Mb AMI UEFI Legal BIOS with GUI support, ACPI 5.1 compliance wake up events, jumperfree, SMBIOS 2., CPU, CPU VDDCR_SOC, DRAM, VDDP Voltage Multi-adjustment
Graphics: HDMI 2.1, D-Sub
Audio: 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec), Surge Protection
LAN: PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111H, Wake-On-LAN, Lightning/ESD Protection, Energy Efficient Ethernet 802.3az, PXE
Slots: 1x PCI Express 3.0 x16 Slot (PCIE2: x16 mode), 1x PCI Express 3.0 x1 Slot
Storage: 1x Ultra M.2 Socket (M2_1, Key M), 4 x SATA3 6.0 Gb/s Connectors
RAID: RAID 0, RAID 1 and RAID 10 for SATA storage devices
Form Factor: Micro ATX Form Factor: 23.0 cm x 20.1 cm
OS: Microsoft Windows 10 64-bit / 11 64-bit
Connector:
1x SPI TPM Header
1x COM Port Header
1x Chassis Intrusion and Speaker Header
1x CPU Fan Connector (4-pin)*
2x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)**
1x 24 pin ATX Power Connector
1x 4 pin 12V Power Connector
1x Front Panel Audio Connector
2x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
1x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
Rear Panel I/O:
1x PS/2 Mouse/Keyboard Port
1x D-Sub Port
1x HDMI Port
2x USB 2.0 Ports (Supports ESD Protection)
4x USB 3.2 Gen1 Ports (Supports ESD Protection)
1x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone

Περιεχόμενα συσκευασίας
μητρική A520M-HVS
Quick Installation Guide
Support CD
I/O Shield
2x SATA Data Cables
1x Screw for M.2 Socket
